工业级人体工学全自动气动起子MOT-K-PB系列
●采用单进气双排气结构及特殊材质的叶片；
●交错轨道专利式离合器结构，单点跳脱扭力更稳定，超大扭力范围输出，满足不同锁付需求；
●五轴同步加工，合金钢齿轮，上下同心传动，达到低噪音、低震动、高精度的境界。
机型 | 工作气压(kg/cm²） | 气管 | 扭力范围 | 无载转速 | 适用螺丝牙径(mm) | ||
下压式 | 枪型 | 机械牙 | 自攻牙 | ||||
MOT-K10PB | MOT-K10PB/PG | 5.0 | 6.35 | 0.5~2.0 0.05~0.2 | 1000 | 1.0~2.2 | 1.0~1.7 |
MOT-K20PB | MOT-K20PB/PG | 5.0 | 6.35 | 1.0~8.0 0.1~0.8 | 1000 | 1.7~3.3 | 1.3~2.7 |
MOT-K30PB | MOT-K30PB/PG | 5.0 | 6.35 | 2.0~16 0.2~1.6 | 1800 | 2.2~4.2 | 1.7~3.2 |
MOT-K40PB | MOT-K40PB/PG | 5.0 | 6.35 | 5.0~30 0.5~3.0 | 1000 | 2.8~5.0 | 2.3~4.0 |
MOT-K45PB | MOT-K45PB/PG | 5.0 | 6.35 | 8.0~40 0.8~4.0 | 1000 | 2.8~5.5 | 2.3~4.5 |
MOT-K50PB | MOT-K50PB/PG | 8.0 | 9.5 | 7.0~50 0.7~5.0 | 1400 | 2.9~6.0 | 2.6~4.9 |
MOT-K55PB | MOT-K55PB/PG | 8.0 | 9.5 | 7.0~65 0.7~6.5 | 1000 | 2.9~6.4 | 2.6~5.4 |
MOT-K60PB | MOT-K60PB/PG | 8.0 | 9.5 | 15~95 1.5~9.5 | 550 | 4.1~7.0 | 3.3~6.0 |
MOT-K65PB | MOT-K65PB/PG | 8.0 | 9.5 | 25~120 2.5~12.0 | 150 | 5.0~8.0 | 4.0~7.0 |
